Commercial And Residential PVC Coated Chain Link Fencing 1.5 Inch ISO Listed

Name: Commercial And Residential PVC Coated Chain Link Fencing 15 Inch ISO Listed
Brand: Xmesh
Price: 1 USD

Wholesale Commercial And Residential PVC Coated Chain Link Fencing 1.5 Inch ISO Listed from china suppliers

Brand Name : Xmesh

Model Number : CLFE

Certification : iso

Place of Origin : Hebei

MOQ : 10 rolls

Payment Terms : 30%TT in advance, Balance before loading

Supply Ability : 500 roll per month

Delivery Time : 15-25days

Packaging Details : Bulk

Material : PVC coated Wire, hot dipped galvanized wire

Standard : A975, EN-10244

Wire Dia : 9gauge or 3mm, 4mm, 1.85mm, 2.0mm

Mesh Openning : 50x50mm,60x60mm

Height : 4 feet or 1.8m, 1.2m

Length : 10m or 15m or 25m

Zinc Coating : 40-50gsm, 100-200gsm

Contact Now

Commercial and Residential 1.5inch PVC Coated Chain Link Fencing for kenya market

Chain Link Fence is also named diamond wire mesh with the diamond opening. It is made with various metal wires weaving by chain link fence machine. Our chain link fence materials are available in stainless steel, galvanized, and PVC coated wire. They are normally used in gardens, sports yard, industrial sites, houses, roads and events for crowd control.

Chain link fence mesh, woven from steel wire, is probably the most widely used &
versatile of all fencing fabrics available in a variety of wire gauges & mesh sizes to suit specific applications. All rolls come complete with line wires and with knuckled edges.

Description:

1.Materials of chain link fence : low carbon iron wire
2.Surface treatment: PVC Coated / Hot-dipped galvanized / Electro-galvanized
3.Weaving type: Crocheting and weaving
4.Fence ends treatment: knuckles barb , twisted barb

Galvanized chain link fence and PVC coated chain link fence Main specificatin as follows:

Mesh	Wire Thickness	Surface Treatment	Panel Width	Height
40X40mm 50X50mm 60X60mm 65X65mm 75X75mm	2.0mm - 4.8mm	Galvanized and PVC coated Or Hot dipped galvanized	10m 15m 18m 20m 25m 30m	1200mm
				1500mm
				1800mm
				2000mm
				2100mm
				2400mm
				2500mm
				3000mm
				3600mm

Application
Chain Link Fence normally used in gardens, sports yard, industrial sites, houses, roads and events for crowd control.Here are some product actual installation rendering.

Standards:
ASTM A392 Type 1 – Zinc-Coated Steel Chain Link Fence Fabric ASTM F567 – Installation of Chain Link Fence
ASTM A817 – Metallic-Coated Wire for Use in Chain Link Fence ASTM B6 – Zinc (Slab Zinc)
Federal Specification RR-F-191K/1F Type 1 Fencing, Wire and Post Metal (Chain-Link Fence) AASHTO M-181 Chain Link Fence, Type 1

Commercial And Residential PVC Coated Chain Link Fencing 1.5 Inch ISO Listed

chain link fence Features:
Good materials, uniform mesh, flat surface, simple weaving, elegant, practical, and flexible installation.

chain link fence Applications:
Playground ( tennis ground ,football ground, basketball ground )
Building site.
Courtyard, park, lwan, forest protecting

chain link fence Standard Colors :
Only Galvanized
moss green RAL 6005

Packaging & Shipping
Commercial And Residential PVC Coated Chain Link Fencing 1.5 Inch ISO Listed

Chain Link FAQ :

1. Are all chain-link fences the same?
Chain-link has four elements: fabric ( chain link mesh ), framework, fittings and gates. How you combine them makes all the difference. Each of these components are available in a range of weights (gauges) and types of protective coatings. Providers can mix and match components in an effort to shave costs or differentiate their product. Our minimum recommendations will typically follow the minimum practices defined by the American Society for Testing and Materials (ASTM). The most common coating is zinc (galvanized), but you’ll also find chain-link components with vinyl or polyester color coatings in addition to zinc. These color treatments enhance landscaping and blend naturally with trees, shrubs and bushes. They’ll also give you even more protection against corrosion or rust.

2.What do I look for in residential chain link fabric?
Select your chain-link fence fabric based on these three criteria: gauge of wire, size of mesh and type of protective coating.

3.How do I select my residential fence framework?
Start with the gauge and the outside diameter. Below is a helpful table that you may use in selecting your fence framework. “Terminal Posts” is a generic term for end, corner and gate posts. Gate posts will vary based on the size of the gate.

Application		Light Duty	Medium Duty	Heavy Duty
3’-4’ high	Toprail	1-3/8” 17 ga.	1-3/8” 16 ga.	1-3/8” 15 ga.
	Line Posts	1-5/8” 17 ga.	1-5/8” 16 ga.	1-5/8” 15 ga.
	Terminal Posts	1-7/8” 17 ga.	1-7/8” 16 ga.	1-7/8” 15 ga.
5’-6’ high	Toprail	1-3/8” 17 ga.	1-3/8” 16 ga.	1-5/8” 15 ga.
	Line Posts	1-7/8” 17 ga.	1-7/8” 16 ga.	1-7/8” 15 ga.
	Terminal Posts	2-3/8” 17 ga	2-3/8” 16 ga.	2-3/8” 15 ga.
